FAPC 016-12105 Argo Hytos oil service unit with oil cleanliness monitor 16 lit/min 230V 1ph

Price and availability SHIPPING WORLDWIDE
REQUEST PRICE & AVAILABILITY

Availability: Inquire about stock

Price and availability

Payment and shipping methods

Visa · Mastercard · PayPal · Stripe · Google Pay

DHL · FedEx · UPS

Product identification

Hidraoil Part number
GFX103324
Brand
Argo Hytos
Identification number
FAPC 016-12105
Other numbers
FAPC016-12105 FAPC 016 12105 FAPC01612105 34292600
Approximate weight (kg)
24,0

Description

Portable filtration unit with integrated particle monitoring for hydraulic fluids, including mineral oils and biodegradable fluids.
Compact, portable design for efficient fluid cleaning, with contamination-level indication during filling or cleaning.
Nominal flow: 16 liters/minute.
Electric motor voltage: 230V single-phase, 50/60 Hz (IP55).
Electric motor power: 0.45 kW at 50 Hz.
Maximum viscosity: 150 mm2/s (695 SUS).
Minimum viscosity: 15 mm2/s (70 SUS).
Fluid temperature range: 0-60 ºC (32-140 ºF).
Maximum suction lift: 1.5 meters.
Maximum PRV pressure: 4 bar (58 psi).
Clogging indicator: Visual, via a pressure gauge.
Particle monitor: OPCom. Accurate fluid cleanliness measurements require viscosity between 15 and 150 mm2/s (70-695 SUS).
