TXV150 0525070 Hydro Leduc hydraulic piston pump variable displacement 150 cm3 LS splined shaft z8 CW rotation e izquierdas
Price and availability SHIPPING WORLDWIDEThe images are indicative and may differ from the final product delivered.
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX101520
- Brand
- Hydro Leduc
- Identification number
- TXV150 0525070
- Other numbers
- TXV 150 TXV1500525070 load sensing
- Approximate weight (kg)
- 27,2
Description
Type: Variable displacement for open circuits, with LS (load-sensing) displacement control.
Maximum displacement: 150 cm3/rev.
Flow @ 1500 rpm: 225 liters/minute.
Maximum working pressure: 310 bar.
Maximum intermittent pressure: 330 bar (max 5%).
Maximum rotational speed: 1900 rpm.
Rotation: Clockwise or counterclockwise rotation.
Control type: Pressure and flow control, LS (load sensing) system.
Shaft type: Splined 8 tooth.
Flange type: Square flange with 80 mm centering diameter and mounting holes on a square pattern with 80 mm side spacing.
More information
- Category: Hydraulic Pumps
- Category: Piston
- Category: Axial
- Category: Variable displacement
- Category: Hydro Leduc
- Category: TXV
- Category: 150cc
- Last updated: 2016-12-22 23:25:58
