151B2047 OMT 250 Danfoss hydraulic orbital motor 250 cm3 splined shaft US version
SHIPPING WORLDWIDE
The images are indicative and may differ from the final product delivered.
REQUEST PRICE & AVAILABILITY
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX107025
- Brand
- Danfoss
- Identification number
- 151B2047 OMT 250
- Other numbers
- 151B 2047 OMT250 Sauer Danfoss 151B2U47
- Approximate weight (kg)
- 21,0
Description
Hydraulic orbital motor Danfoss for high torque applications.
Shaft type: Splined with 17 teeth.
Flange type: Square type with 4 holes and 127 mm centering diameter.
Displacement: 251.8 cm3/rev.
Side Ports: Threaded 1 1/16 - 12 UN.
Drain Port: 9/16 - 18 UNF.
Max speed: 500 rpm (intermittent operation: 600 rpm).
Max. Torque: 730 Nm (intermittent operation: 880 Nm).
Max. Output Power: 33,5 kW (intermittent operation: 40 kW).
Max. Pressure Drop: 200 bar (intermittent operation: 240 bar; peak: 280 bar).
Max oil flow: 125 liters/minute (intermittent operation: 150 liters/minute).
Shaft type: Splined with 17 teeth.
Flange type: Square type with 4 holes and 127 mm centering diameter.
Displacement: 251.8 cm3/rev.
Side Ports: Threaded 1 1/16 - 12 UN.
Drain Port: 9/16 - 18 UNF.
Max speed: 500 rpm (intermittent operation: 600 rpm).
Max. Torque: 730 Nm (intermittent operation: 880 Nm).
Max. Output Power: 33,5 kW (intermittent operation: 40 kW).
Max. Pressure Drop: 200 bar (intermittent operation: 240 bar; peak: 280 bar).
Max oil flow: 125 liters/minute (intermittent operation: 150 liters/minute).
More information
- Category: Hydraulic Motors
- Category: Orbital
- Category: Sauer Danfoss
- Category: OMT
- Last updated: 2023-11-15 12:00:00
