Product identification

• Hidraoil Part number: GFX101181
• Brand of product: Plessey
• Part number: A48
• Approximate weight (kg): 3,5

Description

• Hydraulic external gear pump with aluminum case of group 2.
  Flange type: European with 36.5 mm centering diameter and 4 holes with 96.1 x 71.4 mm distance between centers.
  Displacement: 22 cm3/rev.
  Flow @ 1500 rpm: 33 liters/minute.
  Shaft type: Tapered 1:8.
  Rotation: Counterclockwise rotation (looking at the pump shaft from the front).
  Inlet port: Italian Flange type D40 M8.
  Outlet port: Italian Flange type D30 M6.
