F12-030-MF-IV-P-000-0000-P0 3721568 Parker hydraulic piston motor 30 cm3
SHIPPING WORLDWIDE
The images are indicative and may differ from the final product delivered.
REQUEST PRICE & AVAILABILITY
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX106805
- Brand
- Parker
- Identification number
- F12-030-MF-IV-P-000-0000-P0 3721568
- Approximate weight (kg)
- 12,0
Description
Hydraulic Piston Motor fixed displacement for applications with high demands. Motor version prepared to add a speed sensor.
Displacement: 30.0 cm3/rev.
Shaft type: Cilyndrical shaft 25 mm diameter.
Flange type: ISO flange type with 4 holes and centering diameter 100 mm
Ports A and B: Flanges type SAE 6000.
Drain port: M18x1.5.
Rotation: Bidirectional.
Max speed: 6700 rpm (intermittent operation: 7300 rpm).
Minimum rotation speed: 50 rpm.
Max working pressure: 350 bar.
Max oil flow: 201 liters/minute (intermittent operation: 219 liters/minute).
Torque at 100 bar: 47,6 Nm.
Shaft seal material: Type V.
Intermittent working value is allowed for up to maximum of 6 seconds per minute.
Check specific conditions for operating this product as hydraulic pump.
Displacement: 30.0 cm3/rev.
Shaft type: Cilyndrical shaft 25 mm diameter.
Flange type: ISO flange type with 4 holes and centering diameter 100 mm
Ports A and B: Flanges type SAE 6000.
Drain port: M18x1.5.
Rotation: Bidirectional.
Max speed: 6700 rpm (intermittent operation: 7300 rpm).
Minimum rotation speed: 50 rpm.
Max working pressure: 350 bar.
Max oil flow: 201 liters/minute (intermittent operation: 219 liters/minute).
Torque at 100 bar: 47,6 Nm.
Shaft seal material: Type V.
Intermittent working value is allowed for up to maximum of 6 seconds per minute.
Check specific conditions for operating this product as hydraulic pump.
More information
- Category: Hydraulic Motors
- Category: Piston
- Category: Axial
- Category: Fixed displacement
- Category: Parker
- Category: F12
- Last updated: 2023-10-17 07:30:00
