TXV130 0518705 Hydro Leduc hydraulic piston pump variable displacement 130 cm3 LS splined shaft z8 CCW rotation (through shaft)
SHIPPING WORLDWIDE
The images are indicative and may differ from the final product delivered.
REQUEST PRICE & AVAILABILITY
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX101524
- Brand
- Hydro Leduc
- Identification number
- TXV130 0518705
- Other numbers
- TXV 130 TXV1300518705 load sensing through shaft
- Approximate weight (kg)
- 31,1
Description
Hydraulic axial piston pump from cilindrada variable preparada para montar una bomba trasera.
Type: Variable displacement for open circuit con control from cilindrada LS (sensor from carga).
Max displacement: 130 cm3/rev.
Flow @ 1500 rpm: 195 liters/minute.
Max working pressure: 360 bar.
Max Pressure intermittent: 380 bar (max 5%).
Velocidad from giro máxima: 1900 rpm.
Rotation: Counterclockwise rotation.
Control Type: Control from presión y caudal, sistema LS (Load Sensing).
Shaft type: Splined 8 tooth.
Flange type: Cuadrada con centraje from diámetro 80 mm y distancia entre centros from agujeros en cuadrado from 80 mm from lado.
Type: Variable displacement for open circuit con control from cilindrada LS (sensor from carga).
Max displacement: 130 cm3/rev.
Flow @ 1500 rpm: 195 liters/minute.
Max working pressure: 360 bar.
Max Pressure intermittent: 380 bar (max 5%).
Velocidad from giro máxima: 1900 rpm.
Rotation: Counterclockwise rotation.
Control Type: Control from presión y caudal, sistema LS (Load Sensing).
Shaft type: Splined 8 tooth.
Flange type: Cuadrada con centraje from diámetro 80 mm y distancia entre centros from agujeros en cuadrado from 80 mm from lado.
More information
- Category: Hydraulic Pumps
- Category: Piston
- Category: Axial
- Category: Variable displacement
- Category: Hydro Leduc
- Category: TXV
- Category: 130cc
- Last updated: 2016-12-22 23:42:01
