WMTF-S125 Hidraoil hydraulic motor PTO 125 cm3 20 CV 540 rpm with agriculture PTO splined shaft z6
SHIPPING WORLDWIDE
The images are indicative and may differ from the final product delivered.
REQUEST PRICE & AVAILABILITY
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX102404
- Brand
- Hidraoil
- Identification number
- WMTF-S125
- Other numbers
- WMTFS125
- Approximate weight (kg)
- 10,4
Description
Hydraulic motor for use as an alternative hydraulic power take-off on a tractor.
Shaft type: 6-tooth agricultural splined shaft (P.T.O. type), 34.9 mm outside diameter.
Flange type: Standard 4-hole flange, with 125 mm pilot diameter and 160 mm hole centre-to-centre diameter.
Displacement: 125 cm³/rev.
Side ports: G3/4 threaded ports (3/4" BSPP).
Flow required at 540 rpm: Approximately 65 litres/minute.
Pressure required to generate 20 hp at 540 rpm: 160 bar.
Maximum permitted operating values for the motor:
Max. oil flow: 75 litres/minute.
Maximum pressure drop: 175 bar.
Drawing dimensions:
Max. L: 176 mm.
Agricultural applications: Slurry agitators, rotary tillers, flail mowers and similar implements. Confirm with the implement manufacturer that motor output power is sufficient.
Shaft type: 6-tooth agricultural splined shaft (P.T.O. type), 34.9 mm outside diameter.
Flange type: Standard 4-hole flange, with 125 mm pilot diameter and 160 mm hole centre-to-centre diameter.
Displacement: 125 cm³/rev.
Side ports: G3/4 threaded ports (3/4" BSPP).
Flow required at 540 rpm: Approximately 65 litres/minute.
Pressure required to generate 20 hp at 540 rpm: 160 bar.
Maximum permitted operating values for the motor:
Max. oil flow: 75 litres/minute.
Maximum pressure drop: 175 bar.
Drawing dimensions:
Max. L: 176 mm.
Agricultural applications: Slurry agitators, rotary tillers, flail mowers and similar implements. Confirm with the implement manufacturer that motor output power is sufficient.
More information
- Category: Hydraulic Motors
- Category: Orbital
- Category: Hidraoil
- Category: By application
- Category: Alternative PTO
- Category: Range S
- Last updated: 2019-11-10 06:49:00
