151-0406 OMR 250 Sauer Danfoss hydraulic orbital motor 250 cm3 straight shaft 25,4 mm without drain port
SHIPPING WORLDWIDE
The images are indicative and may differ from the final product delivered.
REQUEST PRICE & AVAILABILITY
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX101341
- Brand
- Sauer Danfoss
- Identification number
- 151-0406 OMR 250
- Other numbers
- 1510406 OMR250
- Approximate weight (kg)
- 8,5
Description
Hydraulic orbital motor for high torque applications. Geroller type.
Shaft type: Parallel 25.4 mm diameter with 6.4 mm key width.
Flange type: SAE-A Type 2 holes A2 Flange with 82.5 mm centering diameter and 106.4 mm distance between holes..
Gearwheel set case width (L1): 43,5 mm.
Displacement: 249,3 cm3/rev.
Side Ports: Threaded 1/2" GAS.
Drain Port: Without Drain port.
Max speed: 240 rpm (intermittent operation: 300 rpm).
Max. Torque: 300 Nm (intermittent operation: 380 Nm; peak load:600 Nm).
Max. Output Power: 6 kW (intermittent operation: 8 kW).
Max. Pressure Drop: 80 bar (intermittent operation: 110 bar; peak load:200 bar).
Max oil flow: 60 liters/minute (intermittent operation: 75 liters/minute).
Max. starting pressure with unloaded shaft: 5 bar.
Min. starting torque at max. press. drop cont.: 240 Nm.
Min. starting torque at max. press. drop int.: 310 Nm.
Intermittent operation: the permissible values may occur for max. 10% of every minute.
Peak load: the permissible values may occur for max. 1% of every minute.
Shaft type: Parallel 25.4 mm diameter with 6.4 mm key width.
Flange type: SAE-A Type 2 holes A2 Flange with 82.5 mm centering diameter and 106.4 mm distance between holes..
Gearwheel set case width (L1): 43,5 mm.
Displacement: 249,3 cm3/rev.
Side Ports: Threaded 1/2" GAS.
Drain Port: Without Drain port.
Max speed: 240 rpm (intermittent operation: 300 rpm).
Max. Torque: 300 Nm (intermittent operation: 380 Nm; peak load:600 Nm).
Max. Output Power: 6 kW (intermittent operation: 8 kW).
Max. Pressure Drop: 80 bar (intermittent operation: 110 bar; peak load:200 bar).
Max oil flow: 60 liters/minute (intermittent operation: 75 liters/minute).
Max. starting pressure with unloaded shaft: 5 bar.
Min. starting torque at max. press. drop cont.: 240 Nm.
Min. starting torque at max. press. drop int.: 310 Nm.
Intermittent operation: the permissible values may occur for max. 10% of every minute.
Peak load: the permissible values may occur for max. 1% of every minute.
More information
- Category: Hydraulic Motors
- Category: Orbital
- Category: Sauer Danfoss
- Category: OMR
- Category: Straight shaft 25.4 mm
- Category: Without case drain
- Last updated: 2015-12-11 17:03:28
