PVPC-C-4046/1D Atos hydraulic piston pump variable displacement 46 cm3 with cylindrical shaft and manual pressure compensator
SHIPPING WORLDWIDE
The images are indicative and may differ from the final product delivered.
REQUEST PRICE & AVAILABILITY
Availability: Inquire about stock
Price and availabilityPayment and shipping methods
Visa · Mastercard · PayPal · Stripe · Google Pay
DHL · FedEx · UPS
Product identification
- Hidraoil Part number
- GFX102628
- Brand
- Atos
- Identification number
- PVPC-C-4046/1D
- Other numbers
- PVPC-C-4046/1D 11 PVPC-C-4046/1D 12 PVPCC40461D PVPCC40461D11 PVPCC40461D12 PVPC C 4046 1D 11 12
- Approximate weight (kg)
- 24,0
Description
Hydraulic Piston pump Variable Displacement.
Displacement: 46 cm3/rev.
Flow @ 1450 rpm: 66.7 liters/minute.
Max working pressure: 280 bar.
Rotation: Clockwise rotation (looking at the pump shaft from the front).
Control Type: Control by setting pressure mechanically. Pump displacement is reduced when system pressure reaches control set pressure.
Pressure setting range: Entre 20 y 350 bar. De fábrica, el mando está regulado up to 280 bar.
Speed range: From 500 to 2600 rpm. For higher speed than 1800 rpm; pump inlet must be below oil tank level and inlet line dimensions must be well designed.
Shaft type: Parallel diameter 1" (25.4 mm) con chaveta from ancho 1/4" (6.35 mmm).
Displacement: 46 cm3/rev.
Flow @ 1450 rpm: 66.7 liters/minute.
Max working pressure: 280 bar.
Rotation: Clockwise rotation (looking at the pump shaft from the front).
Control Type: Control by setting pressure mechanically. Pump displacement is reduced when system pressure reaches control set pressure.
Pressure setting range: Entre 20 y 350 bar. De fábrica, el mando está regulado up to 280 bar.
Speed range: From 500 to 2600 rpm. For higher speed than 1800 rpm; pump inlet must be below oil tank level and inlet line dimensions must be well designed.
Shaft type: Parallel diameter 1" (25.4 mm) con chaveta from ancho 1/4" (6.35 mmm).
More information
- Category: Hydraulic Pumps
- Category: Piston
- Category: Axial
- Category: Variable displacement
- Category: Atos
- Category: PVPC
- Category: C-Pressure manual control
- Category: Straight shaft
- Last updated: 2020-03-14 11:58:00
